Product Specifications
Profile Reinforcement | 1.8-3.0mm |
Finish Treatment | Powder Coating |
Frame Depth | 168mm |
Frame Width | 21mm |
Sash Width | 46mm |
Max. Leaf Width | 1377-4000mm |
Max. Leaf Height | 700-1200mm |
Glass Standard | 34mm(8G+18A+8G) Double Toughened Clear Glass, Filled with Argon Gas |
Glazing Pocket | Less than 34 mm |
Glass Spacer | Black Aluminum Spacer |
Glass Type | Double Panes,Triple Panes, Clear, Ultra Clear, Low-e, Laminated, Reflective, Frosted, Obscure...Glass |
Hardware | China Brand |
Screens | Motorized Polyester Mesh Screen |
Blinds | No Blinds |
Standard | Comply with ISO9001, CE, NFRC, AS2047, CSA Certification |
Warranty | 10 Years - Terms and conditions apply |
Product Features
Seamless Panoramic View & Adaptive Space Design The lift-and-slide system features an ultra-thin 2.1cm middle frame and 8mm tempered glass fixed panel. Its horizontal split frame design allows for a 95% unobstructed view while instantly converting between an open-air terrace (upper sash fully retracted) and a weatherproof enclosure. The patented wind-proof wing structure and 3.0mm thick 6063-T6 aluminum profiles can withstand wind loads of less than 4,500Pa, making it ideal for coastal balconies or high-rise sunrooms seeking spatial flexibility.The intermediate transom can also bear the weight of three adults (about 200kg). | Intelligently driven silent operation and safety The load-bearing system uses a composite material made of BASF materials for flexible connections. The high-precision industrial-grade brushless motor provides 25dB silent operation and 0.1mm height adjustment accuracy. The intelligent safety beam immediately reverses the sash movement when an obstacle is detected, while the child lock mode and IP68-level sealing prevent accidents. Maintenance-free composite rails and modular access ports ensure over 100,000 uses in wet climates, and paired with the optional electric insect screen (0.5mm mesh), it allows for seamless indoor-outdoor living. |
Download
●
2025 Rolansini Window and Door Catalog.pdf;
● T9 Panoramic Up Down Lifting Slide Motorized Window Profile Section;
● Up Down Lifting Slide Motorized Window Measurement&Installation;
● Care&Maintenance Guaidance.
